RJR BAX Stereo Equalizer
The RJR BAX is an extremely clean stereo baxandall equalizer. It has the ability to mould and shape the tonal balance of source audio while imposing no artifacts or distortion at all, even at high boost or cut settings. It can be built in dual mono or stereo ganged configuration, with smooth turn potentiometers or stepped controls, with or without high and low pass filters, and with the many other optional features available it's possible to create a custom RJR BAX that will give you a new level of tonal control over your audio.
The following are a few examples of custom ordered RJR BAX equalizers. These units have already been built and shipped to the customers that ordered them, and are not available for immediate order. If you would like to order a custom RJR BAX equalizer, or if you would like to inquire about pricing, available options, or have any other questions, please inquire on the CONTACT page! Due to the complexities involved in custom orders, please be aware that there is usually a lead time of several months for a custom order.
Built for Arcade Mastering. Dual mono; 12 position low cut filter; 12 position high cut filter; parallel blend control; 24 position ELMA rotary switches for all boost/cut controls, mid frequency sweep, and parallel blend; five individually selectable output transformers from UTC, Jensen, Carnhill, Sowter, and Cinemag; switch to move all transformers from output to input; reproduction RCA knobs; black anodize panel with no infill engraving.
Dual mono; sweepable potentiometers for all boost/cuts and mid frequency; 6 position switches for high and low bax shelves; 12 position switches for HPF and LPF; switchable UTC A-20 and Western Electric 111C transformers; switch to move all transformers from output to input; rare vintage 2" ivory resin RCA knobs for boost/cut controls; turquoise powdercoat panel with white infill.
Built for David Kidd. Stereo ganged; 24 position ELMA switches for all boost/cuts; 6 position switches for all frequency bands; 6 position switches for HPF and LPF; switchable UTC A-20 and Cinemag CMOB transformers; rare vintage Ernest Turner VU meter; synth style knobs; black powdercoat panel with white infill.
Dual mono; sweepable potentiometers for all boost/cuts and mid frequency; 6 position switches for high and low bax shelves; 6 position switches for HPF; replica Marconi knobs; black anodize panel with no infill.
Stereo ganged; sweepable potentiometers for all boost/cuts and mid frequency; 6 position switches for high and low bax shelves; 6 position switches for HPF and LPF; switchable Lundahl transformers; RCA and chickenhead knobs; black anodize panel with no infill.
Stereo ganged; 24 position ELMA switches for all boost/cut controls; 6 position switches for high, mid, and low frequencies; 6 position switch for HPF; switchable Sowter transformers; rare vintage 2" ivory resin RCA knobs for boost/cut controls; turquoise powdercoat panel with white infill.
Dual mono; 24 position ELMA switches for all boost/cuts; 12 position switch for mid frequency; 6 position switches for high and low bax shelves; 6 position switch for HPF; switchable Edcor transformers; black anodize panel with no infill.
Stereo ganged; 24 position ELMA switches for all boost/cuts; 6 position switches for high, mid, and low frequencies; 6 position switch for HPF; Sifam AL20SQ VU meter; switchable Lundahl transformers; vintage style knobs; aluminum grey powdercoat panel with black infill.
Dual mono; smooth turn potentiometers for all boost/cuts and mid frequency; 6 position switches for high and low bax shelves; 4 position switch for HPF; chickenhead knobs; turquoise powdercoat panel with white infill.
Built for Arcade Mastering; Dual mono; 24 position ELMA switches for all boost/cuts; 6 position switches for high, mid, and low frequencies; 4 position switch for HPF; reproduction Dakaware knobs; gold anodize panel with black infill.
Dual mono; smooth turn potentiometers for all boost/cuts and mid frequency; 6 position switches for high and low bax shelves; 12 position switch for HPF; chickenhead knobs; black anodize panel with no infill.
Dual mono; smooth turn potentiometers for all boost/cuts and mid frequency; 6 position switches for high and low bax shelves; 12 position switch for HPF; KILO HD knobs; black anodize panel with no infill.
Stereo ganged; smooth turn potentiometers for all boost/cut controls; 6 position switches for high, mid, and low frequencies; 4 position switch for HPF; black anodize panel with no infill.
Dual mono; 24 position ELMA switches for all boost/cuts; 6 position switches for high, mid, and low frequencies; 4 position switch for HPF; reproduction Dakaware knobs; red anodize panel with yellow infill.
Dual mono; 24 position ELMA switches for all boost/cuts; 6 position switches for high, mid, and low frequencies; 4 position switch for HPF; reproduction Dakaware knobs; green anodize panel with white infill.
Dual mono; smooth turn potentiometers for all boost/cuts and mid frequency; 6 position switches for high and low bax shelves; 6 position switches for HPF and LPF; switchable Sowter transformers; black aluminum knobs; green anodize panel with white infill.
Built for Miles Walker; Dual mono; 24 position ELMA switches for all boost/cuts and mid frequency; 6 position switches for high and low bax shelves; 5 position switch for HPF; KILO HD knobs; black anodize panel with orange and white infill.
Dual mono; smooth turn potentiometers for all boost/cuts and mid frequency; 6 individual toggle switches for each high and low bax shelf; 4 position switch for HPF; chickenhead knobs; turquoise powdercoat panel with white infill.
